Fixed Inductors
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | Type | Material - Core | Inductance | Tolerance | Current Rating (Amps) | Current - Saturation (Isat) | Shielding | DC Resistance (DCR) | Q @ Freq | Frequency - Self Resonant | Ratings | Operating Temperature | Inductance Frequency - Test | Features | Mounting Type | Supplier Device Package | Size / Dimension | Height - Seated (Max) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
BWHP001107066N8J00INDUCTOR RF Pulse Electronics |
0 |
|
Datasheet |
BWHP | 0402 (1005 Metric) | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ceramic | 6.8 nH | ±5% | 1.5 A | - | Unshielded | 95mOhm Max | 25 @ 250MHz | 5.8GHz | - | -40°C ~ 125°C | 250 MHz | - | Surface Mount | 0402 | 0.043" L x 0.028" W (1.10mm x 0.70mm) | 0.026" (0.65mm) |
|
|
BWHP0011070647NG00INDUCTOR RF Pulse Electronics |
0 |
|
Datasheet |
BWHP | 0402 (1005 Metric) | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ceramic | 47 nH | ±2% | 420 mA | - | Unshielded | 720mOhm Max | 30 @ 250MHz | 2.4GHz | - | -40°C ~ 125°C | 250 MHz | - | Surface Mount | 0402 | 0.043" L x 0.028" W (1.10mm x 0.70mm) | 0.026" (0.65mm) |
|
|
BWHP001107064N3J00INDUCTOR RF Pulse Electronics |
0 |
|
Datasheet |
BWHP | 0402 (1005 Metric) | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ceramic | 4.3 nH | ±5% | 1.6 A | - | Unshielded | 60mOhm Max | 22 @ 250MHz | 7.15GHz | - | -40°C ~ 125°C | 250 MHz | - | Surface Mount | 0402 | 0.043" L x 0.028" W (1.10mm x 0.70mm) | 0.026" (0.65mm) |
|
|
BWHP001107067N5G00INDUCTOR RF Pulse Electronics |
0 |
|
Datasheet |
BWHP | 0402 (1005 Metric) | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ceramic | 7.5 nH | ±2% | 1.4 A | - | Unshielded | 130mOhm Max | 25 @ 250MHz | 5.4GHz | - | -40°C ~ 125°C | 250 MHz | - | Surface Mount | 0402 | 0.043" L x 0.028" W (1.10mm x 0.70mm) | 0.026" (0.65mm) |
|
|
BWHP0011070647NH00INDUCTOR RF Pulse Electronics |
0 |
|
Datasheet |
BWHP | 0402 (1005 Metric) | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ceramic | 47 nH | ±3% | 420 mA | - | Unshielded | 720mOhm Max | 30 @ 250MHz | 2.4GHz | - | -40°C ~ 125°C | 250 MHz | - | Surface Mount | 0402 | 0.043" L x 0.028" W (1.10mm x 0.70mm) | 0.026" (0.65mm) |
|
|
BWHP001107064N3H00INDUCTOR RF Pulse Electronics |
0 |
|
Datasheet |
BWHP | 0402 (1005 Metric) | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ceramic | 4.3 nH | ±3% | 1.6 A | - | Unshielded | 60mOhm Max | 22 @ 250MHz | 7.15GHz | - | -40°C ~ 125°C | 250 MHz | - | Surface Mount | 0402 | 0.043" L x 0.028" W (1.10mm x 0.70mm) | 0.026" (0.65mm) |
|
|
BWHP0011070643NH00INDUCTOR RF Pulse Electronics |
0 |
|
Datasheet |
BWHP | 0402 (1005 Metric) | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ceramic | 43 nH | ±3% | 450 mA | - | Unshielded | 720mOhm Max | 29 @ 250MHz | 2.5GHz | - | -40°C ~ 125°C | 250 MHz | - | Surface Mount | 0402 | 0.043" L x 0.028" W (1.10mm x 0.70mm) | 0.026" (0.65mm) |
|
BWCT001609062N5K00INDUCTOR RF Pulse Electronics |
0 |
|
Datasheet |
BWCT | 0603 (1608 Metric) | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ceramic | 2.5 nH | ±10% | 1.3 A | - | Unshielded | 60mOhm Max | 20 @ 250MHz | 11GHz | - | -40°C ~ 125°C | 250 MHz | - | Surface Mount | 0603 | 0.063" L x 0.035" W (1.60mm x 0.90mm) | 0.024" (0.60mm) |
|
|
BWHP001107069N0G00INDUCTOR RF Pulse Electronics |
0 |
|
Datasheet |
BWHP | 0402 (1005 Metric) | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ceramic | 9 nH | ±2% | 1.4 A | - | Unshielded | 90mOhm Max | 28 @ 250MHz | 5GHz | - | -40°C ~ 125°C | 250 MHz | - | Surface Mount | 0402 | 0.043" L x 0.028" W (1.10mm x 0.70mm) | 0.026" (0.65mm) |
|
|
BWCT001609062N3J00INDUCTOR RF Pulse Electronics |
0 |
|
Datasheet |
BWCT | 0603 (1608 Metric) | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ceramic | 2.3 nH | ±5% | 1.6 A | - | Unshielded | 46mOhm Max | 25 @ 250MHz | 11GHz | - | -40°C ~ 125°C | 250 MHz | - | Surface Mount | 0603 | 0.063" L x 0.035" W (1.60mm x 0.90mm) | 0.024" (0.60mm) |
