Fixed Inductors
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | Type | Material - Core | Inductance | Tolerance | Current Rating (Amps) | Current - Saturation (Isat) | Shielding | DC Resistance (DCR) | Q @ Freq | Frequency - Self Resonant | Ratings | Operating Temperature | Inductance Frequency - Test | Features | Mounting Type | Supplier Device Package | Size / Dimension | Height - Seated (Max) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
MPIA4040R1-100-RFIXED IND 10UH 1.2A 370 MOHM SMD |
0 |
|
Datasheet |
MPIA4040 | Nonstandard | Tape & Reel (TR) | Obsolete | Molded | Metal Composite | 10 µH | ±20% | 1.2 A | 2.8A | Shielded | 370mOhm Max | - | - | AEC-Q200 | -55°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.175" L x 0.160" W (4.45mm x 4.06mm) | 0.047" (1.20mm) |
|
|
MPIA4040R1-1R0-RFIXED IND 1UH 3.7A 40 MOHM SMD |
0 |
|
Datasheet |
MPIA4040 | Nonstandard | Tape & Reel (TR) | Obsolete | Molded | Metal Composite | 1 µH | ±20% | 3.7 A | 7.7A | Shielded | 40mOhm Max | - | - | AEC-Q200 | -55°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.175" L x 0.160" W (4.45mm x 4.06mm) | 0.047" (1.20mm) |
|
|
MPIA4040R1-1R5-RFIXED IND 1.5UH 3A 60 MOHM SMD |
0 |
|
Datasheet |
MPIA4040 | Nonstandard | Tape & Reel (TR) | Obsolete | Molded | Metal Composite | 1.5 µH | ±20% | 3 A | 6.5A | Shielded | 60mOhm Max | - | - | AEC-Q200 | -55°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.175" L x 0.160" W (4.45mm x 4.06mm) | 0.047" (1.20mm) |
|
|
MPIA4040R1-2R2-RFIXED IND 2.2UH 2.6A 80 MOHM SMD |
0 |
|
Datasheet |
MPIA4040 | Nonstandard | Tape & Reel (TR) | Obsolete | Molded | Metal Composite | 2.2 µH | ±20% | 2.6 A | 5.9A | Shielded | 80mOhm Max | - | - | AEC-Q200 | -55°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.175" L x 0.160" W (4.45mm x 4.06mm) | 0.047" (1.20mm) |
|
|
MPIA4040R1-3R3-RFIXED IND 3.3UH 2.2A 115MOHM SMD |
0 |
|
Datasheet |
MPIA4040 | Nonstandard | Tape & Reel (TR) | Obsolete | Molded | Metal Composite | 3.3 µH | ±20% | 2.2 A | 5.1A | Shielded | 115mOhm Max | - | - | AEC-Q200 | -55°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.175" L x 0.160" W (4.45mm x 4.06mm) | 0.047" (1.20mm) |
|
|
MPIA4040R1-4R7-RFIXED IND 4.7UH 1.8A 180MOHM SMD |
0 |
|
Datasheet |
MPIA4040 | Nonstandard | Tape & Reel (TR) | Obsolete | Molded | Metal Composite | 4.7 µH | ±20% | 1.8 A | 3.8A | Shielded | 180mOhm Max | - | - | AEC-Q200 | -55°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.175" L x 0.160" W (4.45mm x 4.06mm) | 0.047" (1.20mm) |
|
|
MPIA4040R1-6R8-RFIXED IND 6.8UH 1.5A 250MOHM SMD |
0 |
|
Datasheet |
MPIA4040 | Nonstandard | Tape & Reel (TR) | Obsolete | Molded | Metal Composite | 6.8 µH | ±20% | 1.5 A | 3.2A | Shielded | 250mOhm Max | - | - | AEC-Q200 | -55°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.175" L x 0.160" W (4.45mm x 4.06mm) | 0.047" (1.20mm) |
|
|
MPIA4040R1-R15-RFIXED IND 150NH 7A 11 MOHM SMD |
0 |
|
Datasheet |
MPIA4040 | Nonstandard | Tape & Reel (TR) | Obsolete | Molded | Metal Composite | 150 nH | ±20% | 7 A | 26A | Shielded | 11mOhm Max | - | - | AEC-Q200 | -55°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.175" L x 0.160" W (4.45mm x 4.06mm) | 0.047" (1.20mm) |
|
|
MPIA4040R1-R22-RFIXED IND 230NH 5.5A 18 MOHM SMD |
0 |
|
Datasheet |
MPIA4040 | Nonstandard | Tape & Reel (TR) | Obsolete | Molded | Metal Composite | 230 nH | ±20% | 5.5 A | 21A | Shielded | 18mOhm Max | - | - | AEC-Q200 | -55°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.175" L x 0.160" W (4.45mm x 4.06mm) | 0.047" (1.20mm) |
|
|
MPIA4040R1-R33-RFIXED IND 330NH 4.4A 28 MOHM SMD |
0 |
|
Datasheet |
MPIA4040 | Nonstandard | Tape & Reel (TR) | Obsolete | Molded | Metal Composite | 330 nH | ±20% | 4.4 A | 17A | Shielded | 28mOhm Max | - | - | AEC-Q200 | -55°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.175" L x 0.160" W (4.45mm x 4.06mm) | 0.047" (1.20mm) |
|
|
MPIA4040R1-R47-RFIXED IND 470NH 5.2A 20 MOHM SMD |
0 |
|
Datasheet |
MPIA4040 | Nonstandard | Tape & Reel (TR) | Obsolete | Molded | Metal Composite | 470 nH | ±20% | 5.2 A | 11.5A | Shielded | 20mOhm Max | - | - | AEC-Q200 | -55°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.175" L x 0.160" W (4.45mm x 4.06mm) | 0.047" (1.20mm) |
|
|
MPIA4040R1-R68-RFIXED IND 680NH 3.3A 51 MOHM SMD |
0 |
|
Datasheet |
MPIA4040 | Nonstandard | Tape & Reel (TR) | Obsolete | Molded | Metal Composite | 680 nH | ±20% | 3.3 A | 9A | Shielded | 51mOhm Max | - | - | AEC-Q200 | -55°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.175" L x 0.160" W (4.45mm x 4.06mm) | 0.047" (1.20mm) |
|
|
MPIA4040R2-100-RFIXED IND 10UH 1.5A 240 MOHM SMD |
0 |
|
Datasheet |
MPIA4040 | Nonstandard | Tape & Reel (TR) | Obsolete | Molded | Metal Composite | 10 µH | ±20% | 1.5 A | 3.1A | Shielded | 240mOhm Max | - | - | AEC-Q200 | -55°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.175" L x 0.160" W (4.45mm x 4.06mm) | 0.059" (1.50mm) |
|
|
MPIA4040R2-6R8-RFIXED IND 6.8UH 1.8A 158MOHM SMD |
0 |
|
Datasheet |
MPIA4040 | Nonstandard | Tape & Reel (TR) | Obsolete | Molded | Metal Composite | 6.8 µH | ±20% | 1.8 A | 3.4A | Shielded | 158mOhm Max | - | - | AEC-Q200 | -55°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.175" L x 0.160" W (4.45mm x 4.06mm) | 0.059" (1.50mm) |
|
|
MPIA4040R3-100-RFIXED IND 10UH 1.5A 213 MOHM SMD |
0 |
|
Datasheet |
MPIA4040 | Nonstandard | Tape & Reel (TR) | Obsolete | Molded | Metal Composite | 10 µH | ±20% | 1.5 A | 3.8A | Shielded | 213mOhm Max | - | - | AEC-Q200 | -55°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.175" L x 0.160" W (4.45mm x 4.06mm) | 0.071" (1.80mm) |
|
|
MPIA4040R3-150-RFIXED IND 15UH 1.3A 285 MOHM SMD |
0 |
|
Datasheet |
MPIA4040 | Nonstandard | Tape & Reel (TR) | Obsolete | Molded | Metal Composite | 15 µH | ±20% | 1.3 A | 3A | Shielded | 285mOhm Max | - | - | AEC-Q200 | -55°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.175" L x 0.160" W (4.45mm x 4.06mm) | 0.071" (1.80mm) |
|
|
MPIA4040R3-1R2-RFIXED IND 1.2UH 4A 32 MOHM SMD |
0 |
|
Datasheet |
MPIA4040 | Nonstandard | Tape & Reel (TR) | Obsolete | Molded | Metal Composite | 1.2 µH | ±20% | 4 A | 9.4A | Shielded | 32mOhm Max | - | - | AEC-Q200 | -55°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.175" L x 0.160" W (4.45mm x 4.06mm) | 0.071" (1.80mm) |
|
|
MPIA4040R3-220-RFIXED IND 22UH 1.1A 408 MOHM SMD |
0 |
|
Datasheet |
MPIA4040 | Nonstandard | Tape & Reel (TR) | Obsolete | Molded | Metal Composite | 22 µH | ±20% | 1.1 A | 2.2A | Shielded | 408mOhm Max | - | - | AEC-Q200 | -55°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.175" L x 0.160" W (4.45mm x 4.06mm) | 0.071" (1.80mm) |
|
|
MPIA4040R3-6R8-RFIXED IND 6.8UH 2A 120 MOHM SMD |
0 |
|
Datasheet |
MPIA4040 | Nonstandard | Tape & Reel (TR) | Obsolete | Molded | Metal Composite | 6.8 µH | ±20% | 2 A | 4.5A | Shielded | 120mOhm Max | - | - | AEC-Q200 | -55°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.175" L x 0.160" W (4.45mm x 4.06mm) | 0.071" (1.80mm) |
|
|
MPIA4040R4-6R8-RFIXED IND 6.8UH 2.4A 91 MOHM SMD |
0 |
|
Datasheet |
MPIA4040 | Nonstandard | Tape & Reel (TR) | Obsolete | Molded | Metal Composite | 6.8 µH | ±20% | 2.4 A | 3.2A | Shielded | 91mOhm Max | - | - | AEC-Q200 | -55°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.175" L x 0.160" W (4.45mm x 4.06mm) | 0.079" (2.00mm) |
